Aluminum concentric cable with two core copper communication cable

Concentric Cable, Aluminum Copper Concentric Cable, 2*10mm2 Concentric Cable, 2*16mm2 Concentric Cable, 2*10mm2, 2x16mm2 PVC Concentric Cable, Round Concentric Cable

Product Details

Application:

The cables are for the service-entrance.
Service conditions: The cable shall be a service cable for continuous operation outdoors and tropical conditions(temperature range of -1℃ to +40℃,humidity of up to 90% and saline conditions along the coast),suitable for laying in cable ducts and in air, permissible continuous loading operating temperature shall be 70℃ and short circuit temperature of 160℃.

Standard:

BS7870 BS6746,KS04-1022

Construction:

Rated Voltage: 600/1000V
Conductor: Solid or stranded Al conductor
Insulation: PVC
Neutral conductor: Helically Al wire with coverage 100% and non-100% coverage with two core copper communication cable
Cable wrapping tape: Non-absorbent material
External coverage: Weather resistant material PVC Construction

Type:

Size:2x8mm2,2x10mm2,2x16mm2,2x25mm2,2x35mm2
Single core type round with full neutral entrance cable
Single core type round with less neutral entrance cable
Single core type round with full neutral and communication cores entrance cable

Advantages:

1.Factory direct sale
2.Cable manufacturer,ISO,CE
3.Abundant experiences,high quality and cheap price
4.Free cable sample

Specifications

Technical Data:

Core and
Nominal
Cross
Section

Conductor

Insulation
thickness

Concentric
conductor

Thickness of cable shield

Overall cable diameter

Weight
Of cable

Max DC resistance of conductor(20°C)



mm²

Number

Diameter

mm

Number

Diameter
mm

mm

mm

Kg/km

Ω/km

Ω/km
(Concentric)

Copper conductor (IEC Standard)



2*10

7

1.35

1.55

20

0.85

1.40

11.80

290

1.83

1.90

2*16

7

1.70

1.55

32

0.85

1.40

12.84

420

1.15

1.20

2*25

7

2.14

1.60

29

1.13

1.50

15.02

630

0.727

0.76

2*35

19

1.53

1.65

27

1.35

1.60

17.00

832

0.524

0.55

Aluminum alloy conductor (IEC standard)



2*10

7

1.35

1.55

23

1.13

1.40

12.41

192

3.08

1.335

2*16

7

1.70

1.55

26

1.13

1.40

13.46

230

1.91

1.808

2*25

7

2.14

1.6

29

1.13

1.50

15.08

290

1.20

1.0586

2*35

19

1.53

1.65

27

1.35

1.60

17.05

0.868

0.868

0.7966
