Core*Nominal Cross sectional Area | Min No.of stranding wires | Thickness of insulation | Thickness of steel tape | Thickness of sheath | Nominal diameter | Max DC resistance of conductor at 20℃ |
No*mm2 | No/mm | mm | mm | mm | mm | Ω/km |
2*10 | 6 | 1.0 | 0.2 | 1.8 | 19.8 | 1.83 |
2*16 | 6 | 1.0 | 0.2 | 1.8 | 21.8 | 1.15 |
2*25 | 6 | 1.2 | 0.2 | 1.8 | 19.6 | 0.727 |
2*35 | 6 | 1.2 | 0.2 | 1.8 | 21.8 | 0.524 |
2*50 | 6 | 1.4 | 0.2 | 1.8 | 24.6 | 0.387 |
3*10 | 6 | 1.0 | 0.2 | 1.8 | 20.8 | 1.83 |
3*16 | 6 | 1.0 | 0.2 | 1.8 | 22.9 | 1.15 |
3*25 | 6 | 1.2 | 0.2 | 1.8 | 20.7 | 0.727 |
3*35 | 6 | 1.2 | 0.2 | 1.8 | 22.6 | 0.524 |
3*50 | 6 | 1.4 | 0.2 | 1.9 | 25.4 | 0.387 |
4*10 | 6 | 1.0 | 0.2 | 1.8 | 22.4 | 1.83 |
4*16 | 6 | 1.0 | 0.2 | 1.8 | 24.9 | 1.15 |
4*25 | 6 | 1.2 | 0.2 | 1.8 | 23 | 0.727 |
4*35 | 6 | 1.2 | 0.2 | 1.8 | 25.2 | 0.524 |
4*50 | 6 | 1.4 | 0.2 | 2.0 | 28.6 | 0.387 |
